The steel aircraft cable is manufactured in conformity with YB/T5196,YB/T5197 and other overseas high standards.It is widely used in industries such as aviation ,machinery,instruments, and electronics in foreign countries like America.The steel cable has a variety of specifications such as 1X7,1X19,6X7+IWS,6X19+IWS,6X7+NF,6X19+NF and other SERIES

The steel aircraft cable comes with an independent wire rope core.The diameter range is 2mm to 10mm and the length is 10m to 2000m per coil.Made of #60 or #70 steel and featured by small diameter ,high stress,low elongation and longer fatigue life,the seamless steel wire rope is dedicated for aviation with a tensile strength of 1670-2160Mpa.Before delivery,it can be packed with wooden tray, soft coil ,carton,or wooden case. The standard is MIL-W-83420D.

diameter (mm)	EN12385-4
	Minimum breaking force(KN）		Gross weight(Kg/100m)
	1670 N/MM2	1770 N/MM2
2	2.22	2.35	1.38
3	4.99	5.29	3.11
4	8.87	9.40	5.52
5	13.90	14.70	8.63
6	20.00	21.20	12.40
7	27.10	28.80	16.90
8	35.50	37.60	22.10
9	44.90	47.60	27.90
10	55.40	58.80	34.50
11	222.00	235.00	138.00
12	268.00	284.00	167.00
13	319.00	338.00	199.00
14	375.00	397.00	233.00
16	435.00	461.00	270.00
18	568.00	602.00	352.00
20	222.00	235.00	138.00
22	268.00	284.00	167.00
24	319.00	338.00	199.00
26	375.00	397.00	233.00
28	435.00	461.00	270.00
32	568.00	602.00	353.00
